RigExpert AA-55 ZOOM Antenna Analyzer BT
349,00 CHF
289,00 CHF
Économisez 60,00 CHF
TTC
The analyzer is designed for measuring SWR (standing wave ratio), return loss, cable loss, as well as other parameters of cable and antenna systems in the range of 60 kHz to 55 MHz.
Frequency range
- 0.06 to 55 MHz
Frequency entry
- 1 kHz
Measurement for systems
- 25, 50, 75, 100 Ohm
SWR measurement range
- 1 to 10 in chart modes
- 1 to 100 in numerical modes
R and X range
- 0…1000, -1000…1000 in chart modes
- 0…10000, -10000…10000 in numerical modes
Display modes
- R, X chart, 100 points
- Return loss chart, 100 points
- Smith chart, 100 points
- SWR at single or multiple frequencies
- SWR chart, 100 points
- SWR, return loss, R, X, Z, L, C at single frequency
RF output
- Connector type: UHF (SO-239)
- Output power: +13 dBm (at 50 Ohm load)
- Output signal shape: square
Power
- Max. 4 hours of continuous measurement, max. 2 days in standby mode when fully charged batteries are used
- Two 1.2V Ni-MH batteries, type AA
- Two 1.5V alkaline batteries, type AA
- When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources
Interface
- 320×240 color TFT display
- 6x3 keys on the water-proof keypad
- Menus and help screens in English (by default), Japanese, French
- USB connection to a personal computer
Dimensions
- 103 mm x 207 mm x 37 mm (4.1 in x 8.1 in x 1.4 in)
Operating temperature
- 0…40 °C (32…104 °F)
Weight
- 310 g (10.9 Oz) w/o batteries
GTIN-13
- 4820185420099
Note
- Specifications are subject to change without notice
- Мade in Ukraine
61137
